XHXDZ-2312-Continuous sound Active

ADD: 3rd Floor, No. 88 Xinle Road, Xinle Community, Xin

Mob: 13652428659

Download:

Item	Specification
Rated voltage	12VDC
Operation voltage	3～24VAC
Sound Pressure Level=SPL	Min 90dB
Oscillation frequency	3300±500Hz
Response time	Max 50mS
Range of operation temperature	-20～+80℃
Range of preservation temperature	-30～+85℃
Terminal strength	10N
Externals size	Φ22.5*12

200PCS / 1 SMALL CARTON
3000PCS / 1 CARTON (15 SMALL CARTON)
3000PCS/CARTON 15kg 50*42*27CM 0.0567CBM

Item	Specification
Rated voltage	12VDC
Operation voltage	3～24VAC
Sound Pressure Level=SPL	Min 90dB
Oscillation frequency	3300±500Hz
Response time	Max 50mS
Range of operation temperature	-20～+80℃
Range of preservation temperature	-30～+85℃
Terminal strength	10N
Externals size	Φ22.5*12

200PCS / 1 SMALL CARTON
3000PCS / 1 CARTON (15 SMALL CARTON)
3000PCS/CARTON 15kg 50*42*27CM 0.0567CBM
