XHXDZ-2616 waterproof IP68 Active 12V/24V

ADD: 3rd Floor, No. 88 Xinle Road, Xinle Community, Xin

Mob: 13652428659

Download:

Item	Specification
Resonant Frequency (KHZ)	2.8±0.5
Rated Voltage (VDC)	12.0
Operating Voltage (VDC)	6~16
Max. Current Consumption at Rated Voltage (mA)	≤35
Min. Sound Output at 30cm at Rated Voltage (dB)	85
Operating Temperature (0C)	-20~+70
Storage Temperature (0C)	-30~+80
Housing Material	(white)

Item	Specification
Resonant Frequency (KHZ)	2.8±0.5
Rated Voltage (VDC)	12.0
Operating Voltage (VDC)	6~16
Max. Current Consumption at Rated Voltage (mA)	≤35
Min. Sound Output at 30cm at Rated Voltage (dB)	85
Operating Temperature (0C)	-20~+70
Storage Temperature (0C)	-30~+80
Housing Material	(white)
