Item
Specifications
Rated Voltage
3.0VAC
Coil Resistance
12±3Ω
Rated Current（Max）
100mA
Min Sound Output at 10cm
75dB
Resonant Frequency
4000Hz
Operating Temperature
-20~+70℃
Storage Temperature
-40~+85℃
Operating Voltage
2~4VAC
Housing Material
LCP
Lead Pin Material
Red Copper（DAU）
