Size

57×57x35mm

Rated Imp

4ohm±15%

Resonance Freq

120Hz±20%

Output S.P.L.

87±3dB

Rated Power

5.0 W

Max Power

8.0 W

Frequency Range

F0-20 KHz

Insulation Resistance

10MΩ

Magnet

55 × 19 × 10

Polarity

When A Positive D.C Voltage Is Applied To The Terminal Marked (+)
Or Red, The Diaphragm Should Move To The Front
